MODEL

UR1000

UR1500

UR2000

UR3000

UR5000

Capacity

1000VA

1500VA

2000VA

3000VA

5000VA

700W

1050W

1400W

2100W

3500W

AC MODE

Input Voltage

85-145Vac or 145-275Vac

145-275Vac

Input Frequency

45-65Hz

Output Voltage

100-127Vac or 200-240Vac

200-240Vac

INVERTER MODE

Output Voltage

120V±5% or 220V±5%

220V±5%

Output Frequency

50±0.5Hz

Power Factor

0.7

Output Wave Form

Pure Sine Wave

Transfer Time

Typical 2-6ms, 10ms max.

Overload Capacity

110% shut down within 60 seconds; 120% shut down within 5 seconds

Over Current Protection

System shuts down automatically within 20ms

BATTERY

Battery Type

Sealed maintenance-free lead-acid batteries

DC Voltage

24Vdc

48Vdc

QTY & Capacity of Battery

7Ahx2

9Ahx2

7Ahx4

9Ahx4

9Ahx4

Charging Current

1A

Charging Period

6-8 hours recover to 90% capacity

Battery EOD Point

Adjustable

PROTECTION

Full Protection

Low voltage & overload & short circuit protection

INDICATOR

LCD or LED

LCD display

INTERFACE

USB/RJ45 or RS232/RJ45 or None

Optional, support windows XP/Vista, Windows 7/8, Linux, Unix, and MAC

ENVIRONMENT

Operation Temperature

0-40℃

Humidity

20-90% (Non-condensing)

Noise Level

≤40dB(1m away)

Altitude

The altitude should not exceed 1000m,and the height above 1000m

should be reduced to a maximum of 4000m.Refer to IEC62040

PHYSICAL

Net Weight(kg)

16.2

19.2

26.6

28.5

39

Dimension(mm)

441x445x88

441x445x132
